HANDCRAFTED IN DENMARK
- Multiple Playback-heads for true analog tape echoes
- One Record head and two playback heads. Short Head for slap back delay. Long head for longer modern delays, or combine both heads for a semi Delay-Room experience
- Delay time Short head =108 – 520mS. Delay time long head = 215 – 1000 mS
- Tap tempo for Long Head and half the time for the short head
- True Bypass switching with a gold plated relay
- New motor suspension with belt drive, for reduced noise operation
- New Tape deck lock-mechanics to protect pinch roller and tape for longer life span
- All analog signal path from input to output
- Power supply with exchangeable blades 90-240 Volt, and an extra tape cartridge included
- RRP: $999AUD
| Input impedance @ 1KHz | > 500K ohm |
|---|---|
| Output impedance @ 1KHz | >1K ohm |
| Power supply (included) | 12V DC, center negative |
| Current draw @ 12V DC | 300mA |
| Maximum input signal V p-p | 8,7V p-p (12dBu) |
| External connectors | input, output, DC inlet |
| Controls | delay time, feedback, delay level, saturation, kill dry, short, long, on/off, tap tempo |
| Pedal size (W x H x D) | 80 x 174 x 175 mm / 3,15 x 6,85 x 6,89 in |
| Weight excl. packaging | 1,50 kg / 52,91 oz |
