HANDCRAFTED IN DENMARK

  • Multiple Playback-heads for true analog tape echoes
  • One Record head and two playback heads. Short Head for slap back delay. Long head for longer modern delays, or combine both heads for a semi Delay-Room experience
  • Delay time Short head =108 – 520mS. Delay time long head = 215 – 1000 mS
  • Tap tempo for Long Head and half the time for the short head
  • True Bypass switching with a gold plated relay
  • New motor suspension with belt drive, for reduced noise operation
  • New Tape deck lock-mechanics to protect pinch roller and tape for longer life span
  • All analog signal path from input to output
  • Power supply with exchangeable blades 90-240 Volt, and an extra tape cartridge included
  • RRP: $899AUD

Input impedance @ 1KHz > 500K ohm
Output impedance @ 1KHz >1K ohm
Power supply (included) 12V DC, center negative
Current draw @ 12V DC 300mA
Maximum input signal V p-p 8,7V p-p (12dBu)
External connectors input, output, DC inlet
Controls delay time, feedback, delay level, saturation, kill dry, short, long, on/off, tap tempo
Pedal size  (W x H x D) 80 x 174 x 175 mm / 3,15 x 6,85 x 6,89 in
Weight excl. packaging 1,50 kg / 52,91 oz
